`V = pi * ( b /2 )^2 * s * 1 `

Enter a value for all fields

The **Total Engine Displacement** calculator * Engine Cylinders *computes the volume (displacement) of a combustion engine based on the bore, stroke length and number of cylinders.

**INSTRUCTIONS:** Choose units and enter the following:

- (
**b**)**bore**(diameter) - (
**s**)**stroke length** - (
**n**)**number of cylinders**.

**Total Engine Displacement (V):** The total engine displacement volume is returned in cubic inches. However, this can be automatically converted to other cubic units (e.g. cubic centimeters) via the pull-down menu.

The equation for the volume is as follows:

`V = pi * (b/2 )^2 * s * n`

where:

- V = Total Engine Displacement
- b= diameter of cylinders
- s = action length of pistons in cylinders
- n= number of cylinders
